Meridian G 61 R Pre/processore DSP THX surround digitale colore black
€3,999.00
G61 R
Specification
Digital Inputs: (S/PDIF): Five Toslink optical, six coax inputs configured either as individual coax connections or two proprietary six-channel MHR connections
Analog Input: Five L/R stereo, one six-channel analog in, all single-ended
Digital Outputs: (S/PDIF coax): Main L/R, Centre/Sub, sides, rears; A/B (configurable)
Analog Outputs: One single-ended, eight-channel analog output
Analogue ins: 0.5–2.5Vrms adjustable, input impedance 20kohms
Analogue outs: Variable between 0 and 3.5Vrms, output impedance 47ohms.
Distortion <0.01%.
Noise & hum <-95dB CCIR
Control: Two DIN and one BNC for Meridian Comms, three 12V Triggers (150mA), IR, USB, RS232 remote control/configuration
Processing: Three Freescale 56367s and a 56371 running at 150MHz for a total of over 500MIPS (million instructions per second), 48-bit arithmetic throughout
Conversion: 24-bit Sigma-Delta converter chips operating at 96kHz on analog inputs and outputs
Decoding Formats: Include AAC, Dolby Digital, DTS, MPEG Surround,
DSP Modes: Include Direct, Music, Trifield, Ambisonics (two-channel UHJ & B-Format), Super Stereo, Music Logic, THX, Mono, Discrete, TV Logic, ProLogic IIx Music, ProLogicIIx Movie, ProLogic IIx THX, Cinema, and up to 10 user-defined
Dimensions: 17.32" x 3.54" x 13.78" (plus connectors) (WxHxD)
Weight: 19.8 lbs
